Model No. |
S-7 |
S-15 |
S-35 |
|
Pulling capacity: |
1250kg |
2500kg |
5000kg |
|
Test to: |
1500kg |
3000kg |
6000kg |
|
Length of handle |
790mm |
1050mm |
1210mm |
|
Steel wire rope |
IWRC 9mm dia. |
IWRC 12mm dia. |
IWRC 16mm dia. |
|
Net weight ( without wire rope) |
8kg |
22kg |
31.5kg |
|
External dimension |
50×25×10cm |
62×30×15cm |
72×32×14cm |
|
Material casing |
SS41 (JIS) |
SS41 (JIS) |
AL casting |
|
Transmission speed rate per minute |
3meters |
3meters |
3meters |
|
Braking strength of wire rope |
5430kg |
9680kg |
17200kg |
|
safety device |
safety pins |
safety pins |
safety pins |
